Arri L2.76040.B EBB 125/200, 20-34 VDC

Condition: New
  • Offers Available
  • £1 Off Facebook Discount (use code FACEBOOK1OFF at the shopping basket)
Item out of Stock    |  Usually dispatched within 24 hours
This product has been added to your basket...
  • Continue Shopping
  • Checkout

L2.76040.B EBB 125/200, 20-34 VDC, 150 Hz, XLR-4 plug, 125 W-connector: Binder, 200 W-conector: Amphenol, aluminium profile housing

In addition to its well known electronic ballasts, ARRI has developed several DC ballasts: 125/200W, 200/400W and 575/1200W. The two smaller units can be combined with battery belts for use as portable daylight systems. The bigger 575/1200W DC ballast is often used where no AC public net is available.


  •     No additional adaptation required
  •     Detection of the connected luminary through lamp connector
  •     Protection against:

        under/over-voltage on DC input
        DC polarity reversal

  •     Power switches off automatically after 3 seconds when lamp doesn't strike
  •     Detailed service documentation with test procedures
  •     Good service assistance


Electronic Battery Ballast:
  Versions ARRI Battery ARRI Battery
    EBB 125/200 EBB 200/400
  Ident-No. L2.76040.B L2.76270.B
Mains Supply:
  Line Power 225 VA (max.) 250 VA (max.) with 200 W lamp
490 VA (max.) with 400 W lamp
  Supply Voltage 20-36 V DC 20-36 V DC
  Nominal Current 11.2-6.3 A 13-7 A with 200 W lamp
25-13 A with 400 W lamp
  Power Factor - -
Lamp Connection:
  Lamphead connector Binder / Amphenol Amphenol / International
  Lamp Power 125 W / 200 W 200 W / 400 W
  Power Adaption constant control constant control,
automatic detection of lamp type
  Current Characteristic square wave
150 Hz ± 10 Hz
flicker free
square wave,
approx. 110 Hz
flicker free
  Dimming 50-100% of nominal lamp power 50-100% of nominal lamp power
  Starting cold start and hot restrike cold start and hot restrike
  Typical Light Ripple typ. < 3% typ. < 3%
  Dimensions 130 x• 67 x• 158 mm 155 x• 91 x• 26 mm
  Weight ca. 1.2 kg ca. 2.6 kg
  Protective Rate IP 22 IP 21
  Ambient Conditions -20 to +45 °C -20 to +50 °C
  Housing aluminium profile housing aluminium profile housing
  ON / OFF   X
  Protective Earth
  Lamp On
  Over Temperature
  Output Mode (Frequency)
  Remote / DMX
  Detected Lamp Power
  Automatic Lamp Recognition   X
  Automatic Lamphead Recognition
  Active Line Filter (ALF)
  Compensation for Cable Loss (CCL)
  Dimming X X
Output Type:
  50 Hz (low noise)
  60 Hz (low noise)
  75 Hz (flicker free)
  300 Hz (flicker free High Speed)
  1000 Hz (flicker free High Speed
