Sennheiser XSW-D-XLR-MALE-RX -Plug-On Receiver for XSW-D Digital Wireless System (2.4 GHz)

Sennheiser 508497 (508-497, 508/497, 508 497) (XSW/D/XLR/MALE/RX, XSW_D_XLR_MALE_RX) XSW-D-XLR-MALE-RX -Plug-On Receiver for XSW-D Digital Wireless System (2.4 GHz)

Part of the Sennheiser XSW-D digital wireless system, the XSW-D XLR MALE RX XLR plug-on receiver is available as an individual component to be used as a backup receiver or as a replacement unit. It features an XLR-male connector, ready to plug directly into the input of a wide variety of professional audio gear, including mixing boards and portable PA systems.

The XSW-D puts world-renowned Sennheiser wireless sound quality in a miniaturized, plug-and-go, 1-button digital system that anyone can use. Plug it in, power it up, and you're immediately up and running, simplifying your setup so you can concentrate on delivering your performance with confidence.

Easy to Use

• The 1-button, 1-LED concept with single-button interface and status indicator effortlessly handles power and linking tasks for you—without the need for any additional button pressing.

Step Up to Sennheiser Sound Quality

• Sennheiser wireless mic systems are an industry standard, prized by professionals for their clarity and reliability. The XSW-D system allows first-time and budget-conscious users to get their hands on genuine Sennheiser sound quality without breaking the bank.

Clean Audio without Drop Outs

• Nothing ruins a take like hearing the weather report coming through your mic. Unlike traditional analog wireless systems, the XSW-D digital system operates in the 2.4 GHz ISM band, protecting the integrity of your signal from interruptions and drop outs caused by TV channels, radios, or other sources.
• Thanks to Sennheiser's channel allocation and interference management technology, the system selects the best operating frequency and automatically switches to a clean channel to provide reliable transmission at a distance up to 250' line of sight.

License-Free Operation Worldwide

• Because the XSW-D system operates in the license-free 2.4 GHz band, you don't have to worry about local licensing laws, frequency coordination, and other technical hassles.
• Simply let the system pick a channel for you, and start performing—whether you're working at home or anywhere in the world.

System

• Frequency Range: 2.400 to 2.483 GHz
• Latency:
• Transmission Range: 250' / 76.2 m (Line of Sight)
• Simultaneous Operation of Units: Up to 5 Systems Simultaneously
• Frequency Response: 80 Hz to 18 kHz
• Signal-to-Noise Ratio: ≥106 dB
• THD: <0.1 %
• Modulation: GFSK with TDMA
• Operating Temperature: -10 to 55° C / 14 to 131° F
• Relative Humidity: 95% (Non-Condensing)

Receiver

• Type: Plug-On Receiver
• Output Connector: XLR-Male
• Audio Output: -12 dBu, Consumer Line Level (Maximum)
• Battery: Type: Built-In, USB-Rechargeable, Lithium-Ion, Battery Life: 5 Hours, Charging Time: 3 Hours (Typical), Nominal Voltage: 3.7 V, Cell Capacity: 850 mAh
• Input Voltage: 5.0 V (Typical), Charging Temperature: 32 to 140° F / 0 to 60° C
• Dimensions: 4.3 x 0.9 x 1.1" / 109 x 24 x 28 mm

In the box

• Sennheiser XSW-D XLR MALE RX - Plug-On Receiver for XSW-D Digital Wireless System (2.4 GHz)
• USB Type-A to USB Type-C Charging Cable
