Type: Closed-back Dynamic (Headphone) Cardioid Dynamic (Microphone) Driver Diameter: 40 mm (Headphone) Magnet: Neodymium (Headphone) Voice Coil: Copper-clad aluminum wire Frequency Response: 20-20,000 Hz (Headphone) 40-20,000 Hz (Microphone) Maximum Input Power: 1,600 mW at 1 kHz Sensitivity: 100 dB (Headphone) -57 dB (1.4 mV) re 1V at 1 Pa (Microphone) Impedance: 65 ohms (Headphone) 560...
ACOUSTIC & ELECTRICAL SPECIFICATION Acoustic Principle: Externally Biased Condenser Active Electronics: JFET impedance converter with bipolar output buffer Polar Pattern: Cardioid Frequency Range: 20Hz - 20kHz Output Impedance: 63Ω Equivalent Noise (A-weighted): 17 dB SPL (as per IEC651) Maximum SPL: 129 dB SPL Sensitivity: -30.4 dB re. 1 Volt/Pascal (30mV @ 94dB SPL, 1kHz) Power...
Dimensions diameter: 20 mm, length 256 mm Microphone: super-cardioid/lobar Frequency response: 40 Hz to 20 kHz Max. sound pressure level: 132 dB SPL at P48; 126 dB SPL with battery powering Weight: 128 g (without battery) Sensitivity in free field, no load (1kHz): 21 mV/Pa at P48; 19mV/Pa with battery powering Equivalent noise level: 15...
Element: Fixed-charge back plate, permanently polarized condenser Polar Pattern: Cardioid Frequency Response: 20 – 20,000 Hz Power Requirements: USB Power (5V DC) Bit Depth: 16 bit Sample Rate: 44.1/48 kHz Volume Control: Mix control; Headphone volume control Weight: 386 g (13.6 oz) Dimensions: 162.0 mm (6.38") long, 52.0 mm (2.05") maximum body diameter Output Connector: USB-type Headphone Output Power: 130 mW (at 1 kHz, 10% T.H.D.,...
Color : black Wearing style : Headband Impedance : 32 ohms Frequency response : 20-20,000 Hz Sound pressure level (SPL) : 108 dB Ear coupling : Around-Ear (Circumaural) Jack plug : 3.5mm (straight) Cable length : 2.0 m Load rating : 500 mW Acoustics : Acoustic principle: "Dynamic, closed" Harmonic distortion : <0.1% Weight w/o...
Microphone: dynamic Frequency response: 50 to 16,000 Hz (–3 dB) THD, total harmonic distortion: ≤ 0.9% Pick-up pattern: cardioid Signal-to-noise ratio: ≥ 103 dBA RF output power: 10 mW Switching bandwidth: up to 24 MHz Operating time: approx. 10 hrs Modulation: wideband FM Output voltage: 1/4“ (6.3 mm) jack socket (unbalanced): +6 dBu, XLR socket...
USB C interface for charging Input voltage: typ. 5.0 V Charging temperature: 0 °C - 60 °C (32 °F - 140 °F) Charging time: typ. 3 h Battery pack Cell type: Li-Ion Nominal voltage: 3.7 V Cell capacity: 850 mAh Operating time: up to 5 h AF characteristics Codec: aptX® Live Audio frequency response: 3.5...
Analog Performance Sound Field: Mono Operating Principle: Pressure Gradient Transducer: Condenser Polar Pattern: Cardioid Frequency Range: 20 Hz to 20 kHz Signal to Noise Ratio: 68 dB A-Weighted Equivalent Noise Level: 28 dB A-Weighted Maximum SPL: 144 dB SPL Peak THD: < 1% Sensitivity: 6 mV/Pa at 1 kHz CMRR: 60 dB Dynamic Range: 111...
Dimensions: Ø 19 x 250 mm Frequency response (Microphone): 40 - 20000 Hz Sensitivity in free field, no load (1kHz): 25 mV/Pa +- 1 dB Nominal impedance: 25 Ω Min. terminating impedance: 800 Ω Equivalent noise level: 13 dB Equivalent noise level weighted as per CCIR 468-3: 24 dB Maximum sound pressure level (passiv): 130...
EK 100 G4 Frequency range: GB: 606 - 648 MHz Dimensions : Approx. 82 x 64 x 24 mm Compander : Sennheiser HDX THD, total harmonic distortion: ≤ 0.9 % Weight (incl. batteries): approx. 160 g Audio output: 3.5 mm jack socket: +12 dBu (mono, unbalanced) Signal-to-noise ratio: ≥ 110 dBA Switching bandwidth: up to 42...
