Generic Spec:
GENERAL SPECIFICATIONS (GY-HM600 / GY-HM650)
Power
DC 12V (AC adaptor), DC 7.2V (Battery)
Power consumption
Approx. 12W (with VF and LCD monitor)
Dimensions
178(W) x 198(H) x 416(D)mm (7" x 7-13/16" x 16-3/8")
Mass
Appro.2.4kg (5.3lbs):GY-HM600, 2.45kg(5.4lbs):GY-HM650 (Including battery)
Operating temperature
0 to 40 (32 to 104 )
Storage temperature
-20 to 50 (14 to 122 )
Operating humidity
35% to 80%
Storage humidity
Under 85%
CAMERA
Image sensor
1/3" 2.2M pixels progressive scan 3CMOS
Synchronizing system
Internal synchronization
Stabilizer
Optical image stabilizer
Lens
Fujinon F1.6-3.0, 23x, f=4.1-94.3mm (35mm conversion:29 to 667mm)
Filter diameter
72mm
Shutter speed
1/4 to 1/10000
Gain
-6, -3, 0, 3, 6, 9, 12, 15, 18 dB, Lolux, ALC
ND filter
1/4, 1/16, 1/64
LCD display
3.5” 920K pixels, 16:9
Viewfinder
0.45” 1.22M pixels, 16:9
VIDEO/AUDIO RECORDING
Recording media
2x SDHC/SDXC memory card Class 6/10
Video recording
Video codec: MPEG2 Long GOP(HD), AVCHD, H.264(SD)
File format: MOV(HD/SD:H.264), MP4(XDCAM EX), MTS(AVCHD), MXF(GY-HM650 only)
Recording mode
MPEG-2 Long GOP
NTSC setting: HQ mode:1920 x 1080/59.94i, 29.97p, 23.98p, 1440 x 1080/59.94i,
1280 x 720/59.94p, 29.97p, 23.98p
SP mode: 1440 x 1080/59.94i
PAL setting: HQ mode:1920 x 1080/50i, 25p, 1440 x 1080/50i
