Swit 100w Long Ratio Ultra Slim Rgbw Light

SWIT 100w Long Ratio Ultra Slim Rgbw Light(VANGO-100L, VANGO100L, VANGO/100L)

3x0.5’ Long Ratio, 21mm Ultra Slim

With SWIT unique Edge Mounted SMD and 90° high efficient light guide tech, the VANGO-100L has a ultra slim size to only 21mm thickness, and diffused to soft light to paint the entire environment.

Time Division Tech, Brighter Color Light

The regular RGB panels are high bright in CCT mode, but much lower in RGB color mode. That’ s because in a regular RGB light, the RGB color LED and White LED have fixed rates to share the total power of the light, and when output color lights, the RGB LEDs use only 1/3 power. By SWIT unique Time Division Drive tech, full power of the light can be assigned to RGB color LEDs, and greatly increased the intensity of color light. The 100W VANGO-100L color light intensity equals to a regular 300W RGB color light intensity.

Control Panel

VANGO-100L rear control panel supports 5-pin DMX in & out, 4-pin XLR DC 11-36V in, and V-mount battery plate (Gold mount for option), and a large color LCD with menu and hot keys for convenient color picking. The USB-A port is for firmware update or user color profile upload, and to power wireless DMX receiver.

Bluetooth APP Control

Download “SWIT Console” APP on IOS App Store or Google PLAY, to connect and control VANGO lights via Bluetooth.

Swanneck Strong Ball Head

VANGO-100L provides a strong swanneck ball head for light stand mounting, both junior pin male and baby pin female.

LED 180pcs RGB + 300pcs W SMD LEDs

Illuminance 1800Lux @ 1m

Beam Angle 65°

Color Temperature 2800K～10000K, G/M±1.00

CRI 96

TLCI 93

Power 100W

DMX DMX512, 5pin XLR IN & OUT

USB USB-A power out & firmware update

Input voltage 4pin XLR, DC 11V～34V IN

Dimension 839×163×21mm

Lighting area 780×104mm

Weight Net 5.7kg with barndoor; With package 10kg

In the Box

SWIT 100w Long Ratio Ultra Slim Rgbw Light
