Marshall VAC-12HUC HDMI to USB-C Converter

Marshall VAC-12HUC (VAC/12HUC, VAC_12HUC, VAC12HUC, VAC 12HUC) HDMI to USB-C Converter

10-bit input sampling makes a visible difference

The VAC-12HUC converts HDMI 2.0 to USB-C (USB3.0/USB2.0) up to UHD 3840x2160p at 30fps. HDMI input has active loop-thru allowing the original high-quality source to be routed to monitors or other equipment as a pass thru. Common applications include live streaming, video conferencing and other PC or MAC-based applications.

Power is supplied by the USB-C connection to the host computer reducing clutter and eliminating the need for an external power supply. The rugged and compact design makes for easy portability and mobility.

The VAC-12HUC's simple plug-and-play design uses UVC protocol to enable itself as a Camera Device. UVC protocol allows the host computer to set the parameters for the USB stream such as resolution, frame rate and aspect ratio.

Inputs / Outputs

• Video Inputs:  1x HDMI (2.0) Female
• Audio Inputs:  1x 1/8" / 3.5 mm TRS Stereo Analog Female
• Video Outputs: 1x HDMI (2.0) Female (Loop Output), 1x USB-C (USB Video) Female
• Audio Outputs: No
• Expansion Slots: No

Format Support

• Input Video Format: HDMI, UHD 4K 30 fps, 576p, 576i / 625 lines, 480p, 480i / 525 lines
• Input Audio Format: Analog: 48 kHz
• Output Video Format: USB-C, DCI 4K 30 fps, 720p 30 fps
• Embedded Audio: HDMI

Standards

• HDCP Support: Yes, Version 2.2
• HDR Support: Not Specified by Manufacturer


Hardware

• OS Compatibility: Windows 10, Windows 11, macOS

Environmental

• Operating Temperature: 32 to 72°F / 0 to 40°C

Other

• Weight: 1.195 lb
• Dimensions (LxWxH): 8.1 x 6 x 3"

In The Box

• Marshall HDMI to USB-C Converter
• USB-A to USB-C 3.0 Cable
• 2 x Mounting Bracket
• 8 x Mounting Screw
• Limited 1-Year Manufacturer Warranty
