Leica-R SUMMICRON set 6x lens mid 80's, used

Leica-R SUMMICRON set 6x lens mid 80's, used(FMP59910KSBR)

3 months warranty and Like new condition

BEAUTIFUL SET: MID 1980s!

LEICA-R GLASS

SET F. SUMMICRON | MID 1980s

Leica-R Cinemodded set of six vintage lenses

28/2.8 Leica Elmarit-R I (3368434 / 1985)

35/2.0 Leica Summicron-R II (3363961 / 1985)

50/2.0 Leica Summicron-R II (3567702 /1991)

60/2.8 Leica Macro-Elmarit-R (3744339 / 1996)

90/2.0 Leica Summicron-R (3118897 / 1981)

135/2.8 Leica Elmarit-R II  (3341334 / 1984)

Leica-R set custom built case

Completely hand-picked & customized

These vintage Leica-R lenses (mid 1980s) are famous for their soft, yet very sharp look with beautiful bokeh. The lenses have all had a full Cleaning, Lubrication and Adjustment (CLA) so they run as smooth as possible. In addition, they have had a correct declick (no creeping aperture) which makes the aperture stepless.

The lenses feature a sturdy EF mount from Leitax, follow focus gears from Simmod (with rubber inner rings and metal outer rings), 80mm OD / 77mm ID step-up rings and custom engraved caps from the same Canadian company Simmod. The lenses are delivered in a brand new HPRC 2400 case with custom inlay specially manufactured for this Leica-R set.

Cinemodded, serviced and tested

The lenses were technically tested, fully serviced and modified to the highest standards. They were serviced as a full set aimed for use in film making. Special attention was given to light and smooth focusing mechanics that allow pleasant handheld operation as well as usage on focusing motors at the low power setting.

In addition, attention was given to match the focusing and aperture feel across the set. Finally, the lenses were assembled with special techniques and tightened strongly with the aim to minimize the effect of focus click resulting in sudden jumps in the image when reversing focusing direction, an issue with vintage stills lenses used for film making that weren’t properly serviced.

Certificates by our servicing partner are provided



The Leica Elmarit-R 28/2.8 is a beautiful wide angle lens with a field of view of 76° on FF considered to be the better performer optically compared to the wider 24/2.8 and 19/2.8. With its weight of only 378 g / 13.3 oz and a close focus distance of 30 cm / 11.81 in, it’s a versatile and pleasant wide angle on S35 as well as FF/LF cameras.

Leica Elmarit-R 28/2.8 version I

PART OF SET F – CRON | MID 1980s – AVAILABLE

Serial number / year: 3368434 / 1985

Production era: 1970-1992 – 50,510+ lenses

Focal length: 28 mm

Aperture range: f/2.8 – f/22

Lens elements/groups: 8 / 8

Close focus distance: 30 cm / 11.8 in

Aperture blades: 8

Coverage: Full frame / Large Format

Diagonal field of view (FF): 76°

Length (minimum, front to EF-flange): 5.36 cm / 2.1 in

Length (maximum, front to EF-flange): 5.74 cm / 2.3 in

Weight on camera: 378 g / 13.3 oz

Weight total including caps: 424 g / 15.0 oz

Front step-up ring/cap manufacturer: SIMMOD Lens

Front outer diameter (step-up ring OD): 80 mm

Front inside thread (step-up ring ID): 77 mm

Front material: 360° knurled edge, solid billet aluminium and anodized black

Front cap: 360° knurled edge, solid billet aluminium and anodized red

Focus gear: SIMMOD SIMple Fit Follow Focus Gear, mod 0.8 aluminum / 10 mm width with compressible insert

EF mount manufacturer: Leitax

Leica Summicron-R 35/2.0

PART OF SET D – CRON/LUX | EARLY 1970s – AVAILABLE

The Leica Summicron-R 35/2.0 is a beautiful standard to wide angle lens with a field of view of 63° on FF and an be considered as the gem of this set of Leica-R glass. Its whopping close focus distance of only 30 cm / 11.81 in, in combination with its wonderful 2.0 bokeh makes this lens a go-to for many cinematographers.  With its acceptable weight of 620 g / 21.9 oz and a close focus distance of 30 cm / 11.81 in, it’s a versatile and pleasant wider standard on S35 and a great standard on FF/LF cameras.

Leica Summicron-R 35/2.0 version I

PART OF SET D – CRON/LUX | EARLY 1970s – AVAILABLE

Serial number / year: 2904698 / 1978

Production era: 1972-1976 – 11,316 + lenses

Focal length: 35 mm

Aperture range: f/2.0 – f/16

Lens elements/groups: 9 / 7

Close focus distance: 30 cm / 11.8 in

Aperture blades: 6

Coverage: Full frame / Large Format

Diagonal field of view (FF): 64°

Length (minimum, front to EF-flange): 7.40 cm / 2.9 in

Length (maximum, front to EF-flange): 8.04 cm / 3.2 in

Weight on camera: 620 g / 21.9 oz

Weight total including caps: 666 g / 23.5 oz

Front step-up ring/cap manufacturer: SIMMOD Lens

Front outer diameter (step-up ring OD): 80 mm

Front inside thread (step-up ring ID): 77 mm

Front material: 360° knurled edge, solid billet aluminium and anodized black

Front cap: 360° knurled edge, solid billet aluminium and anodized red

Focus gear: SIMMOD SIMple Fit Follow Focus Gear, mod 0.8 aluminum / 10 mm width with compressible insert

EF mount manufacturer: Leitax

Leica Summicron-R 50/2.0

PART OF SET F – CRON | MID 1980s – AVAILABLE

The Leica Summicron-R 50/2.0 is a beautiful standard to close lens with a field of view of 47° on FF and is an absolute camera-sticking lens for FF, being developed for the exact same format back in the day. The still cameras used to be sold with a nifty-fifty attached to it. It’s an absolute wonderful lens with a great bokeh. It has a close focus distance of 50 cm / 19.7 in, and a weight of only 408 g / 14.4 oz, making it the lightest lens in the set, a pleasure to walk around with. Try it and it will not leave your camera.

Leica Summicron-R 50/2.0 version II

PART OF SET F – CRON | MID 1980s – AVAILABLE

Serial number / year: 3567702 /1991

Production era: 1976-2009 – 99,736+ lenses

Focal length: 50 mm

Aperture range: f/2.0 – f/16

Lens elements/groups: 6 / 4

Close focus distance: 50 cm / 19.7 in

Aperture blades: 6

Coverage: Full frame / Large Format

Diagonal field of view (FF): 47°

Length (minimum, front to EF-flange): 5.59 cm / 2.2 in

Length (maximum, front to EF-flange): 6.18 cm / 2.4 in

Weight on camera: 408 g / 14.4 oz

Weight total including caps: 454 g / 16.0 oz

Front step-up ring/cap manufacturer: SIMMOD Lens

Front outer diameter (step-up ring OD): 80 mm

Front inside thread (step-up ring ID): 77 mm

Front material: 360° knurled edge, solid billet aluminium and anodized black

Front cap: 360° knurled edge, solid billet aluminium and anodized red

Focus gear: SIMMOD SIMple Fit Follow Focus Gear, mod 0.8 aluminum / 10 mm width with compressible insert

EF mount manufacturer: Leitax

Leica Macro-Elmarit-R 60/2.8

PART OF SET F – CRON | MID 1980s – AVAILABLE

The Leica Macro-Elmarit-R 60/2.8 is a beautiful and very useful lens in this set. It works great for all macro shots but has an absolute stunning and sharp performance as a standard 60 mm. Because of this double bill you get a lot of bang for buck with this lens! In situations shooting a close object going to normal operation is only a focus pull away. It has a weight of only 516 g / 18.2 oz and a close focus distance in normal operation of only 27 cm / 10.6 in, and only a few centimeters or a mere inch in macro operation. Don’t leave home without this sixty!

Leica Macro-Elmarit-R 60/2.8 late version

PART OF SET F – CRON | MID 1980s – AVAILABLE

Serial number / year: 2887237 / 1978

Production era: 1972-2009 – 46,500+ lenses

Focal length: 60 mm Macro

Aperture range: f/2.8 – f/22

Lens elements/groups: 6 / 5

Close focus distance: 27 cm / 10.6 in

Aperture blades: 6

Coverage: Full frame / Large Format

Diagonal angle of view (FF): 40°

Length (minimum, front to EF-flange): 7.60 cm / 3.0 in

Length (maximum, front to EF-flange): 10.70 cm / 4.0 in

Weight on camera: 516 g / 18.2 oz

Weight total including caps: 562 g / 19.8 oz

Front step-up ring/cap manufacturer: SIMMOD Lens

Front outer diameter (step-up ring OD): 80 mm

Front inside thread (step-up ring ID): 77 mm

Front material: 360° knurled edge, solid billet aluminium and anodized black

Front cap: 360° knurled edge, solid billet aluminium and anodized red

Focus gear: SIMMOD SIMple Fit Follow Focus Gear, mod 0.8 aluminum / 10 mm width with compressible insert

EF mount manufacturer: Leitax

Leica Summicron-R 90/2.0

PART OF SET F – CRON | MID 1980s – AVAILABLE

The Leica Summicron-R 90/2.0 is a beautiful portrait lens with a field of view of 27° on FF, making it a stunning ens for interviews. Its bokeh is absolutely stunning and very pleasant for the skin that is being filmed. It has a close focus distance of 70 cm / 27.6 in, and a weight of 630 g / 22.2 oz and as such it will do great on a tripod for beauty shots.

Leica Summicron-R 90/2.0 early version

PART OF SET F – CRON | MID 1980s – AVAILABLE

Serial number / year: 3118897 / 1981

Production era: 1970-2000 – 37,954+ lenses

Focal length: 90 mm

Aperture range: f/2.0 – f/16

Lens elements/groups: 5 / 4

Close focus distance: 70 cm / 27.6 in

Aperture blades: 8

Coverage: Full frame / Large Format

Diagonal angle of view (FF): 27°

Length (minimum, front to EF-flange): 7.51 cm / 3.0 in

Length (maximum, front to EF-flange): 9.07 cm / 3.6 in

Weight on camera: 630 g / 22.2 oz

Weight total including caps: 676 g / 23.8 oz

Front step-up ring/cap manufacturer: SIMMOD Lens

Front outer diameter (step-up ring OD): 80 mm

Front inside thread (step-up ring ID): 77 mm

Front material: 360° knurled edge, solid billet aluminium and anodized black

Front cap: 360° knurled edge, solid billet aluminium and anodized red

Focus gear: SIMMOD SIMple Fit Follow Focus Gear, mod 0.8 aluminum / 10 mm width with compressible insert

EF mount manufacturer: Leitax

Leica Elmarit-R 135/2.8

PART OF SET F – CRON | MID 1980s – AVAILABLE

The Leica Elmarit-R 135/2.8  is a beautiful portrait lens with a field of view of 18° on FF, making it a stunning close-up lens, also for a second camera lens in interview settings. Its bokeh is absolutely stunning and very pleasant for the skin that is being filmed. It has a close focus distance of 150 cm / 4 ft + 11 in, and a weight of 819 g / 28.9 oz and as such it will do great on a tripod for beauty shots, just like the 90/2.0.

Leica Elmarit-R 135/2.8 version II

PART OF SET F – CRON | MID 1980s – AVAILABLE

Serial number / year: 3106728 / 1981

Production era: 1970-1992 – 50,510+ lenses

Focal length: 135 mm

Aperture range: f/2.8 – f/22

Lens elements/groups: 5 / 4

Close focus distance: 150 cm / 4 ft + 11 in

Aperture blades: 8

Coverage: Full frame / Large Format

Diagonal angle of view (FF): 18°

Length (minimum, front to EF-flange): 10.54 cm / 4.1 in

Length (maximum, front to EF-flange): 12.11 cm / 4.8 in

Weight on camera: 819 g / 28.9 oz

Weight total including caps: 865 g / 30.5 oz

Front step-up ring/cap manufacturer: SIMMOD Lens

Front outer diameter (step-up ring OD): 80 mm

Front inside thread (step-up ring ID): 77 mm

Front material: 360° knurled edge, solid billet aluminium and anodized black

Front cap: 360° knurled edge, solid billet aluminium and anodized red

Focus gear: SIMMOD SIMple Fit Follow Focus Gear, mod 0.8 aluminum / 10 mm width with compressible insert

EF mount manufacturer: Leitax

Leica Custom Case

This Leica-R set of late 1970s beautiful glass deserves the best and most beautiful case there is. A custom HPRC 2400 case with custom inlay was designed specifically for this set. All lenses sit flush aligned with their caps at the top of the inlay. The tallest 135/2.8 fits in the case as well as the tiniest 28/2.8, without needing to bring along a bigger case! The height of all the lenses reach into the lid of the case; this was done to accommodate the height of the 135/2.8. All cut-outs have a tolerance of .5 mm, so the lenses fit snug and safe when transporting, while slipping into each respective cut-out smoothly with a satisfying whoosh sound.

Leica-R set of six lenses

SET F – CRON | MID 1980s – AVAILABLE

28/2.8 Leica Elmarit-R I (3368434 / 1985)

35/2.0 Leica Summicron-R II (3363961 / 1985)

50/2.0 Leica Summicron-R II (3567702 /1991)

60/2.8 Leica Macro-Elmarit-R (3744339 / 1996)

90/2.0 Leica Summicron-R (3118897 / 1981)

135/2.8 Leica Elmarit-R II  (3341334 / 1984)

Leica-R set custom built case
