Libec HS-450 Tripod System - FS

Libec HS-450 Tripod System - FS(HS-450 , HS 450 , HS450 )

Perfect Balance

Libec's unique continuous perfect counterbalance system enables the camera to perfectly balance at any tilt angle. This smooth balance system makes it a lot easier for users to concentrate on precise camera movements, even when using a telephoto lens at its maximum zoomed position.

Newly Designed Fluid Head

From scratch, the fluid head was designed to dramatically reduce play inside its superior pan and tilt drag units, dramatically increasing its longevity. From start to finish, this new fluid head provides ultra-smooth movements and is equipped with many features that enhance a user's experience.

Counterbalance Meter

Equipped with a counterbalance meter with the measurement range of 0 to 100. This allows users to glance at the head's minimum/maximum inner spring strength, making camera balances on site a piece of cake.

Snap On/Off Plate

The slide plate can be attached and released with just one-touch. Quick and easy setups in the field are easily achieved.

Advanced Drag Unit

The layered metal unit in the drag system ensures operability, durability and reliability. Thanks to the finest silicon grease applied, the advanced drag unit offers smoother starts and ultimately improved backlash control. In addition, the grease provides ordinary pan and tilt movements at a wide temperature range from -40˚C/-40˚F up to +60˚C/+140˚F. The variable 4 step drag pan tilt system features a zero "free" mode option with no friction. Unlike other brand heads, there is no need to store it in its zero "free" mode.

Dual Head

The Dual-head base specification allows for a quick set-up with both 75mm bowl and flat base tripods. The Dual-head base is also compatible with sliders, skater dollies, and photo tripods.

User Friendly Accessory Port

Equipped on the fluid head's side, there are 1/4 and 3/8 inch screw holes allowing users to attach an accessory arm to hold monitors, lights and other accessories. Since the holes are located on the base, the payload capacity, center of gravity and front-rear balance of the head are not affected.

LED Bubble Level

The bubble level is equipped with an LED light allowing users to level a tripod head in the dark. In addition, the counterbalance meter is also illuminated.

Camera Plate

Camera Plate Features Sliding Balance Plate

Camera Mounting Screw 1 x 1/4"-20 Male with Locating Pin

1 x 1/4"-20 Male

1 x 3/8"-16 Male

Balance Plate Sliding Range 1.2" / 30 mm

Head

Base Mount 75 mm Half Ball

Flat Base

Counter Balance Continuous (9.9 to 23.1 lb / 4.5 to 10.5 kg)

Center of Gravity 3.9" / 100 mm

Included Pan Handle Length 10.8" / 275 mm

Bubble Level 1 x Illuminated

Accessory Mounting 1/4"-20 Female Thread

3/8"-16 Female Thread

Pan & Tilt

Drag Control Tilt: Stepped 3-Step

Pan: Stepped 3-Step

Drag Type Fluid

Vertical Tilt +90° to -70°

Independent Pan Lock Yes

Independent Tilt Lock Yes

General

Load Capacity 26.5 lb / 12 kg

Operating Temperature -8 to 92°F / -40 to 60°C

Weight 6.2 lb / 2.8 kg

Packaging Info

Package Weight 9.425 lb

Box Dimensions (LxWxH) 19.7 x 12 x 8.5"

Libec RT40RB 2-Stage Tripod Legs With 75mm Bowl Specs

General

Head Mount Type 75 mm Bowl

Maximum Working Height 5.16' / 1.57 m

Minimum Working Height 18.5" / 47 cm

Closed Length 2.41' / 73.5 cm

Materials Aluminum

Weight 6.8 lb / 3.1 kg

Legs

Leg Lock Type Rotating Locking Lever

Independent Leg Spread No

Leg Sections 3

Packaging Info

Package Weight 11.15 lb

Box Dimensions (LxWxH) 33 x 9 x 8"

Libec SP-2B Ground Spreader Specs

Packaging Info

Package Weight 2.665 lb

Box Dimensions (LxWxH) 20.05 x 7.3 x 6.4"

Libec RC-50 Tripod Case For RT40RB (Black) Specs

Legs

Carrying/Transport Options Connecting Handles, Shoulder Strap

Type of Closure Zipper

Exterior Material Polyester, Polyurethane

Padded Yes

Exterior Dimensions H: 7.0 x W: 8.0 x L: 36.0" / H: 17.8 x W: 20.3 x L: 91.4 cm

Packaging Info

Package Weight 6 lb

Box Dimensions (LxWxH) 36 x 8.5 x 7.9"

In the Box

1x H45 Head

1x RT40RB Tripod

1x SP2B Floor Spreader

1x RC50 Case
