Arri L2.75012.E CB 1200 Choke Ballast, 230 V

code: L2.75012.E
Item out of Stock | Usually dispatched within 24 hours
Loading...
Free Delivery On Orders Over £250

L2.75012.E CB 1200 Choke Ballast, 230 V, 50 Hz, international connector (VEAM), 1,5 m power cable with EU connector

Where flicker-free lighting is not required, ARRI choke ballasts offer a robust, lowcost solution. Choke ballasts are optionallyavailable with DMX remote control, ideal for theatre and event applications.

Features:

  •     Low cost and simple ballast
  •     Robust stainless steel housing
  •     Foldable lever and wheels for easy handling
  •     IP 32 protection class
  •     Good service assistance
  •     Detailed technical documentation



Specification:


 Versions
 Ident-No.
Mains Supply:
 Supply Voltage
 Nominal Current
 Power Factor
Lamp Connection:
 Lamphead connector
 Lamp Power
 Power Adaption
General:
 Dimensions
 Weight
 Protective Rate
 Ambient Conditions
 Housing
Indicators:
 ON/OFF
 Protective Earth
 Remote / DMX




ARRI Choke BallastARRI Choke BallastARRI Choke Ballast
CB 1200CB 2500CB 4000
L2.75012.EL2.75024.EL2.75870.E

230 - 240 V~ / 50 Hz
220 V~ / 60 Hz
1, N, PE
230 - 240 V~ / 50 Hz
220 V~ / 60 Hz
1, N, PE
230 - 240 V~ / 50 Hz
220 V~ / 60 Hz
1, N, PE
7.5 A max15 A max24 A max
cos Φ≈ 0.95 (at 230 V / 50 Hz)cos Φ≈ 0.95 (at 230 V / 50 Hz)cos Φ≈ 0.95 (at 220 V / 60 Hz)

International Connector
(VEAM)
International Connector
(VEAM)
International Connector
(VEAM)
1200 W2500 W4000 W
±19% with ±10%
input variation 230V, 50 Hz
±19% with ±10%
input variation 230V, 50 Hz
-13%+19% with ±10%
nominal mains voltage 230V

398 x 254 x 175 mm398 x 293 x 175 mm 453 x 388 x 488 mm
ca. 20 kgca. 29 kgca. 61 kg
IP 32 IP 32IP 32
-20 to +50 °C-20 to +50 °C-20 to +50 °C
stainless steelstainless steelstainless steel, with wheels

XXX
XXX
 XX
 On / OffOn / Off
