The EB 6/9 kW is available in DMX and high speed versions. Like other recent ballasts from ARRI, it features CCL (Compensation of Cable Loss) technology and the power-saving ALF (Active Line Filter). The EB 6/9 kW uses the housing of the current EB 6000 Baby and is compatible with 6K head-to-ballast cables. The EB 6/9 automatically detects not only the 9,000W and 6,000W lamp but also 6k and 9K lampheads.
Features:
Size of EB 6000 Baby
Can be also used for 6K lampheads
Automatic detection of 6K and 9K lampheads
Automatic detection of 6,000 W and 9,000 W lamps in 9K lampheads
CCL (Compensation of Cable Losses)
ALF (Active Line Filter)
DMX – version of EB 6/9 kW (On/Off; dimming)
High Speed – version of EB 6/9 kW (1,000 Hz; adjustable in range 900–1200 Hz / 75 Hz / 50 Hz)
Specification:
Ballast Name
EB 6/9 kW (DMX)
EB 6/9 kW (DMX, High Speed)
Ident. Nr.:
L2.76181.0
L2.76181KH
Ballast Type:
electronic ballast
electronic ballast
Lamp Power:
6,000W / 9,000W
6,000W / 9,000W
Input Voltage:
"180 - 250 V
50/60 Hz
Input Current (A) nominal:
56 - 44 A
56 - 44 A
Max. Apparent Power (VA):
11200VA
11200VA
Power Factor (cos phi):
approx. 0.98
approx. 0.98
Efficiency %:
approx. 0.91
approx. 0.91
Active Line Filter:
x
x
Ignition:
cold strike and hot restrike (automatically limeted < 1 sec)
cold strike and hot restrike (automatically limeted < 1 sec)
Typical Light Ripple:
< 3%
< 3%
Dimming:
50 - 100% of the nominal value
50 - 100% of the nominal value
DMX Remote Control:
DMX 512 Standard
DMX 512 Standard
DMX Functions:
ballast on/off; dimming of lamp power
ballast on/off; dimming of lamp power
DMX Connector:
XLR 5-pin male and female (in / out)
XLR 5-pin male and female (in / out)
Automatic Lamp Detection:
x
x
Automatic Lamphead Detection:
x
x
Compensation of Cable Losses (CCL):
x
x
LED Indication of Input Voltage:
x
x
LED Indication of Protective Earth:
x
x
LED Inciation of Over Temperature:
x
x
LED Indication Lamp On:
x
x
LED Indication of detected lamp:
x
x
LED Indication of Low Noise Mode:
x
x
High Speed 1000Hz:
–
x
Flicker Free:
x
–
Low Noise 75 Hz:
x
x
Low Noise 50 Hz:
x
x
ON/OFF:
x (illuminated)
x (illuminated)
Dimension:
358 x 263 x 450 mm (H x W x L)
358 x 263 x 450 mm (H x W x L)
Weight:
28 kg
28 kg
Max. Ambient Temp. °C:
50°C
50°C
IP Rating:
IP 22
IP 22
