IDX ED-CP150/4X 4x DUO-C150P Batteries And VL-4X Charger

IDX ED-CP150/4X 4x DUO-C150P Batteries And VL-4X Charger(ED-CP150/4X, EDCP150/4X, ED CP150/4X)

DUO-C150P

IDX introduces the next generation in the popular DUO-C Series, the DUO-CP Series. This advanced version offers power taps like those found in the DUO Series for powering accessories. Newly added non-proprietary USB-C PD port for two-way power delivery and charging when used with the new UC-PD1 compact charger, and of course via D-Tap advanced with the VL-DT1. The UC-PD1 can be used with other portable devices. An an viral and an microbial body for hygienic peace of mind.

The DUO-C150P is the successor of the popular DUO-C150 battery. Ideal compact battery solution for digital cinema cameras and camera stabilizer systems where long runtimes are required. With 145Wh capacity, the DUO-C150P meets the passenger aircraft carry-on limit and can still provide mobile power to cine-style cameras such as the ARRI ALEXA Mini and RED Weapon effortlessly for extended periods at a time. The DUO-C150P also includes two on-battery D-Taps and now features a USB-C port to power accessories as well as charge the battery. Also, V-Torch LED for use in dark environments and SMBus to display battery info via viewfinder on cameras such as ARRI and RED.

VL-4X

The VL-4X is a compact, lightweight, four channel (2+2) simultaneous v-mount charger. The VL-4X will charge a total of four batteries with any two simultaneously. The included AC adapter can also be used as a 90W DC power supply. The VL-4X has many standard safety features, including a recovery charge mode that allows low voltage battery cells to be charged safely.

The VL-4X is a slim, lightweight, affordable 4-channel charger. Dual Simultaneous/Sequential feature charges up to 4 batteries total with any 2 simultaneously. The included AC adapter doubles as a 90W DC power supply.

DUO-C150P

Capacity: 145Wh (14.54V/ 9.93Ah)

Max Output Voltage: 16.8V DC

Nominal Voltage: 14.54V DC

Max Discharge Current: 14A‡

D-Tap: 80W each

USB-C PD: DC 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3A, Max 60W

End Voltage: 11V

Battery Protection: Over-charge, Over-discharge, Over-current, Thermal protection

Ambient Temperature: To charge: 32°F ~ 104°F (50°F ~ 86°F recommended)

To discharge: -4°F ~ 113°F (50°F ~ 104°F recommended)

To store: -4°F ~ 122°F (less than 1 month)

Dimensions: 3.82(W) x 5.75(H) x 2.32(D) inches

Weight: 1.98 lbs approx.

‡ may vary depending on the operating temperature

VL-4X

AC Adapter Input Voltage: AC 100-240V 50/60Hz

AC Adapter: YHY15006000

Power Consumption: 220VA max

Charge Current: 1.9A/ max 2.7A

Charging Method: Constant current/Constant voltage

DC Output: 90W (via included AC adapter)

Operating Temperature: 32°F ~ 104°F

Dimensions: 3.56(W) x 6.96(H) x 9.84(D) inches

Weight (Charger): 2.42 lbs approx.

Weight (AC Adapter): 0.99 lbs approx.

In the Box

4x DUO-C150P Batteries

1x VL-4X Charger
